Specifications
- All electronic setworks controls trimsaw
- Feed is variable
- Saws can be removed quickly to pass boards through
- One power connection to a 460 volt 60 AMP disconnect supplies power to everything
- Controls are mounted on a remote pedestal
- An emergency stop button is located on the control panel
- A floating support can also be installed between the first and second saw
- Includes all motors and starters
- All electrical components are UL listed
- 2 - 10 HP Trim Saw motors
- 1 - 3 HP brake motor that moves the saws
- 1 - 2 HP motor that drives the board chains
- 1 - 1 HP motor on the vibrating conveyor
Available Options
This saw control can be programmable to your specifications.
Get a complete list of options and configurations by giving us a call.
