Specifications
- Hydraulic Cylinders: One 2" x 12" with 1 1/2" rod
- Turning Chain: #100 chain with 3/4" dog width with 13 bits
- Drive: H60TB13 sprocket with bushing, H60SDS25 sprocket with bushing, #60 drive chain, and chain guard
- Drive Shaft: 1 11/16" diameter 1018 cold roll
- Idler Shaft: 1 11/16" diameter 1018 cold roll
- Frame: Base constructed from 3" x 4" tubing, uprights constructed from 8" channel and 4" channel
- Head Frame: Constructed from 3" x 4" x 3/8" angle and various flat bar
- Drive Motor: Charlyn 103-1032 hydraulic motor
- Controls: 2-spool directional valve with single control stick
- Hydraulic Requirements: 10 gpm & 950 psi
Available Options
There is also a Model 120H available, which is deisigned for use with the Model #2 & #3 Sawmills.
Get a complete list of options and configurations by giving us a call.
