Specifications
- Hydraulic Cylinders: Two 2" x 12" with 1 1/2" rod
- Turning Chain: #120 chain with 1" dog width with 13 bits
- Drive: H80TB13 sprocket with bushing, 80Q25 sprocket with bushing, #80 drive chain, and chain guard
- Drive Shaft: 2 3/16" diameter 1018 cold roll
- Idler Shaft: 2 3/16" diameter 1018 cold roll
- Frame: Base constructed from 10" x 25.4 lb. beam, fee constructed from 4" x 6" tubing
- Head Frame: Constructed from 8" x 3" x 4" tubing
- Drive Motor: Charlyn 104-1253 hydraulic motor
- Controls: 2-spool directional valve with single control stick
- Hydraulic Requirements: 12 gpm & 950 psi
Available Options
There is also a Model 100H available, which is deisigned for use with the Model #1 Sawmills.
Get a complete list of options and configurations by giving us a call.
