Specifications
- Feed speed: 90 feet per minute
- Board width maximum: 30 3/4 inches
- Maximum distance between saws: 18 inches
- Board thickness maximum : 3 inches
- Mandrel speed RPM 2,900 RPM
- Saw diameter: 12 inches
- Saw collar diameter: 4 1/4 inches
- Mandrel diameter: 1 15/16 inches
- Pressure roll diameter: 4 1/2 inches
- Feed roll diameter: 2 1/4 inches
- Infeed table length: 5 feet 4 inches
- Outfeed table length: 7 feet 6 inches
- Table width: 31 inches
- Overall length 16 feet
Available Options
Besides the different engine options mentioned above, this edger is also available in a mobile configuration.
Get a complete list of options and configurations by giving us a call.
